Pressure Filters

High pressure filters are used as process filters to protect individual valves or the entire hydraulic circuit from contamination as per ISO 4406. 11 versions are available with operating pressures ranging from 1595 to 6090 psi. A range of products is available to resolve all filter mounting problems, in the following configurations :

In-line, with threaded and flange mounts
Manifold top mounting
Manifold side mounting
Manifold mounting, to DIN 24340 CETOP R 35 H
Manifold threaded/flange mounting in the top extraction filter cartridge version
Duplex versions for continuous operation requirements
The range includes a complete set of valves

Bypass valve
Check valve
Bypass + check valve
Reverse-flow valve
Reverse-flow + bypass valve

Return Filter

Return filters are used as process and safety filters to protect pumps and hydraulic circuits from contamination as per ISO 4406. They are available in 4 styles :

SMP semi-immersed filters for mounting to the oil tank with external/internal filter element
MPT semi-immersed filters for mounting to the oil tank with external/internal filter element
MPH/MPI semi-immersed filters for mounting to the oil tank with external/internal filter element
FRI semi-immersed filters for mounting to the oil tank or in-line, available in the single or duplex versions, with external/internal filter element
The FRI version can also be used as an in-line filter for forced lubrication or off-line systems.

Suction Strainer
STR

Submerged suction filter, flow rates up to 900 l/min (238 gpm), threaded connections from 3/8” to 3” BSP/NPT.
Spin-On filters

Spin-On filters are used as process and safety filters to protect individual pumps, valves or the entire hydraulic circuit from contamination as per ISO 4406. Versions are available with operating pressures ranging from 174 to 508 psi. In-line Spin-On filters can be used for the following purposes :

Suction filters
On the return circuit, for mounting on the line or on the tank cover
In-line for low and medium pressures
Spin-On filters are available in 4 configurations :

Single cartridge in-line
In-line with two parallel cartridges on the same axis
In-line with two parallel cartridges mounted side by side
With single cartridge flange for installation to the tank cover
All versions may be equipped with visual and/or electrical blockage indicators

 Accessories

MP FILTRI provides a full range of hydraulic system accessories. They include

immersed suction filters
fluid filler caps and breather plugs
tank input/output pipe mounting brackets with vibration reduction
modular hose clamps
one- to six-way switches
pressure gauges
and visual and electrical level indicators.


 Float Level Switches

Electrical level indicators. Electrical float level indicators, max. height 500 mm


Stainless Steel Pressure Filters

High pressure in-line stainless steel filters are used as process filters to protect individual valves or the entire hydraulic circuit from contamination as per ISO 4406. Versions are available with operating pressures ranging from 4640 to 15.000 psi. The filters are available in the following configurations :

In-line, with threaded mount
Manifold side mounting
Duplex versions for continuous operation requirements
The range includes a complete set of valves

Bypass valve
Reverse flow valve
Reverse flow + bypass valve
